A7100 Mid Torque Mid Speed HV MG Thin Wing Servo

The Spektrum ™ A7100 digital metal gear servo offers phenomenal performance for sailplanes and other thin wing applications. High voltage capable, the A7100 can produce 8.3kg-cm (115 oz-in) of torque at fast 0.078 sec/60° speeds with 8.4V input. Its low-wear, metal gear drive train is powered by a durable, long-lasting coreless motor and is ball bearing supported for smooth operation. It also features a full aluminum case plus low deadband and extraordinary precision. Like all Spektrum servos, the A7100 delivers reliability, consistency and performance that are second to none.

  • High Voltage (HV) capable (4.8-8.4v input range)
  • Specifically designed for thin wing aircraft models and sailplanes
  • Aluminum servo case helps keep operating temperatures low
  • Low wear and tightly meshed all metal gear train
  • Bearing supported drive train helps maximize smooth operation

Features

  • High Voltage (HV) capable (4.8-8.4v input range)
  • Specifically designed for thin wing aircraft models and sailplanes
  • Class leading performance (8.3kg-cm and .078 sec/60° @8.4v)
  • Aluminum servo case helps keep operating temperatures low
  • Low wear and tightly meshed all metal gear train
  • Bearing supported drive train helps maximize smooth operation
  • Over Current and Temperature protection
  • Operating Frequency: 200hz to 333hz

Product Specs

Application
Airplane
Bearing
Single Ball Bearing
Bushing Or Bearing
Bearing
Connector Type
Universal
Deadband
<1µs
Gear Type
Metal
Input Voltage
4.8V-8.4V
Maximum Servo Speed
0.091 sec/60 deg @ 6.0V; 0.086 sec/60 deg @ 7.4V; 0.078 sec/60 deg @ 8.4V
Maximum Servo Torque
96 oz-in (6.9kg-cm) @ 6.0V; 100 oz-in (7.2kg-cm) @ 7.4V; 115 oz-in (8.3kg-cm) @ 8.4V
Overload Protection
No
Product Application
Sailplane
Product Height
1.38" (35 mm)
Product Length
1.18" (30 mm)
Product Weight
1.0 oz (28g)
Product Width
0.39" (10 mm)
Programmable
No
Prop 65
Prop 65 Warning Icon  California Residents Prop 65 WARNINGS.
Servo Operating Voltage
4.8 - 8.4V (HV)
Servo Size Category
Thin Wing
Servo Type
Digital
Spline Count
25 - Tooth
Water-Resistant
No

Compatibility

No results for your given fitment filters

Product Details

icon-box
In The Box
  • (1) A7100 Wing Servo
  • (1) Double-sided Plastic Servo Arm
  • (1) One Inch Red Anodized Aluminum Servo Arm
