Discontinued | This Item is No Longer Available

Votec 322 PNP, 1400mm

Item No.
FMS - FMM1011P
4.3
Selected Store
Needed to Complete
  • Full-range, 4+ channel transmitter
  • Full-range, 4+ channel receiver
  • 3200mAh 6S LiPo flight battery
  • Compatible LiPo charger
What's in the box?
  • (1) Votec 322 PNP Airplane
  • (1) User Manual

Overview

The Votec 322 is a Swiss two-seat low-wing monoplane based on the Rihn DR-107/DR-109 One Design and designed for amateur construction by MSW Aviation of Wohlen.

The FMS Votec 322 1400mm aerobatic model adopts the streamlined design and scale Hamilton color scheme of its full-scale counterpart. High-torque digital servos ensure that its large control surfaces have dramatic movement for modern aerobatic maneuverability. Built with a hollow wing structure, carbon-fiber tubes and precision ball linkages, this Votec 322 delivers a high-performance 3D experience with outstanding strength and precision.

Removable Side-Force-Generators on the wingtips dramatically improve yaw authority and keep the aircraft “locked-in” during aerobatic maneuvers, especially in knife-edge flight. The power system developed for the Votec 322 harnesses the output of a 6S LiPo battery (sold separately) and features a high-efficiency wooden propeller made with super-stiff material that’s lightweight. Experience high-performance 3D flight and more with the FMS Votec 322 1.4m airplane.

Key Features

  • Screw-together construction—no glue required
  • Hollow-core wing construction provides a lightweight structure
  • Two-piece, plug-in wings and stabilizers
  • Carbon-fiber wing and stabilizer joiner tubes
  • Double-bevel hinge lines and large control surfaces provide 3D throw
  • Powerful brushless 4258, 550Kv outrunner motor
  • High-voltage, Predator 70A brushless ESC
  • Strong, high-efficiency wooden propeller
  • Durable 30-gram digital servos with metal gears
  • Ball-style control horns and linkages for greater precision
  • Side-Force-Generators dramatically improve yaw authority
  • Vivid Hamilton trim scheme
  • Large wheels for operation from grass or paved runways
  • Convenient push-button hatch release
  • Detailed cockpit and pilot figure

Product Specs

Approximate Assembly Time
Less than 1 Hour
Completion Level
Plug-N-Play
Flaps
No
Material
EPO
Minimum Required Radio
4+ channel
Motor Size
Brushless 4258, 500Kv
Power Type
Electric
Product Length
58.67 in (1490mm)
Propeller Size
15 x 7
Receiver
Sold Separately
Recommended Motor Battery
3200mAh 6S LiPo (Sold Separately)
Speed Control
Included
Wingspan
55.12 in (1400mm)
